We've had to switch to micropiling on about 20% of our landed projects in the past three years. Usually it's because the standard piling rig simply cannot fit through the site access, or because we're working so close to existing structures that conventional methods would cause damage. Micropiling isn't our first choice — it's typically more expensive — but when site conditions demand it, it's often the only viable option.

What Makes a Site 'Impossible' for Standard Piling?

Standard piling rigs are large machines. On most landed sites, we can position them and work efficiently. But we've encountered sites where this becomes impossible:

• Access width under 3.5 metres: Most conventional rigs need at least this much clearance to manoeuvre safely
• Overhead obstructions: Power lines, MRT tracks, or neighbouring extensions that limit vertical working space
• Proximity to party walls: When we're rebuilding right up to the boundary, vibrations from standard methods can crack neighbouring foundations
• Existing basement levels: If you're extending a property that already has deep basements, standard equipment often can't work around existing structural elements

We also use micropiles when soil reports show conditions that favour smaller-diameter, high-load-capacity solutions — typically when there are alternating hard and soft soil layers that would make standard piles inefficient.

How Micropiling Actually Works on Landed Sites

Micropiles are typically 100-300mm diameter steel-reinforced piles, compared to the 300-600mm diameter of standard bored piles. The equipment is compact — we can often fit the rig through a standard doorway if necessary.

The process involves drilling a small-diameter hole, inserting a steel casing or reinforcement, then grouting under pressure. What makes them effective isn't their size, but how they transfer loads. Standard piles rely heavily on end-bearing (pushing down on firm soil). Micropiles develop most of their capacity through friction along their length, which means they can achieve similar load ratings in a much smaller footprint.

On a recent terrace house rebuild in Katong, we used micropiles because the access road was too narrow for our standard rig. The micropiles were only 150mm diameter, but by extending them deeper and using high-strength grout, we achieved the same 800kN capacity per pile that standard 300mm piles would have provided.

When We Don't Recommend Micropiling

Micropiling has clear limitations. The process is slower — each pile takes longer to install than a standard pile. The cost per linear metre is higher, and you often need more piles to achieve the same total load capacity.

We don't recommend micropiling when standard methods will work, particularly on larger sites where equipment access isn't constrained. For most landed rebuilds with reasonable access, standard bored piles remain more cost-effective.

We also avoid micropiling in very soft soil conditions where achieving adequate friction capacity would require excessive depths. In these cases, we'll often recommend redesigning the foundation system entirely — perhaps using a raft foundation instead of individual piles.

Costs and Timeline Implications

Micropiling typically costs 40-60% more per pile than standard methods, but this can be misleading. On constrained sites, the alternatives might be even more expensive — such as dismantling neighbouring structures to create access, or using crane-lifted equipment.

Timeline-wise, micropiling adds 2-4 weeks to most landed projects. The installation is slower, but the real time impact comes from the additional design work required. Micropile layouts need more detailed structural analysis, and BCA submissions often take longer because the method is less common for landed residential work.

We always price both options when site conditions are borderline. Sometimes paying extra for micropiling is worthwhile to avoid other complications.

BCA and Structural Considerations

BCA treats micropiles the same as standard piles from a submission perspective, but the structural design requirements are more rigorous. We need to demonstrate adequate load transfer mechanisms and provide detailed grouting specifications.

Our in-house QP typically requires more soil investigation data for micropile designs — standard SPT tests aren't always sufficient. We often need additional testing to characterise the friction parameters along the full depth of the proposed piles.

One advantage: because micropiles are typically grouted their full length, they often provide better performance in variable soil conditions than standard piles, which can settle if intermediate soft layers compress over time.

Can micropiling work on any landed site?

Nearly any site, yes. We've installed micropiles through existing slabs, around existing foundations, and in spaces where we had less than 2 metres of working room. The limiting factor is usually cost rather than technical feasibility.

How long do micropiles last compared to standard piles?

In our experience, properly installed micropiles last as long as standard piles — 50+ years easily. The full-length grouting actually provides better corrosion protection for the steel reinforcement than standard methods in some soil conditions.

Do micropiles require special maintenance?

No ongoing maintenance required. Once installed and load-tested, they perform like any other pile foundation. We provide the same warranty period as standard piling work.

Can we add micropiles to an existing foundation later?

Yes, this is actually one of their advantages. We've used micropiles to underpin existing foundations on several landed renovations where the original foundation was inadequate for new loading. The compact equipment makes this possible without major demolition.

Is micropiling noisy for neighbours?

Less noisy than standard piling, actually. The equipment is smaller and there's no impact driving. Most of the noise comes from the drilling process, which is similar to standard bored piles but typically faster per pile location.

If your landed project involves tight access or challenging soil conditions, we're happy to assess whether micropiling makes sense for your specific situation. Every site is different, and we'd rather spend time upfront determining the right foundation approach than deal with complications during construction.
